HOTSPOT (Drag and Drop is not supported)You have an Azure App Service web app that uses a system-assigned managed identity.You need to recommend a solution to store the settings of the web app as secrets in an Azure key vault. The solution must meet the following requirements:-Minimize changes to the app code.-Use the principle of least privilege.What should you include in the recommendation? To answer, select the appropriate options in the answer area.Note: Each correct selection is worth one point.Hot Area:
Answer(s): A
Box 1: Key Vault references in Application settingsSource Application Settings from Key Vault.Key Vault references can be used as values for Application Settings, allowing you to keep secrets in Key Vault instead of the site config. Application Settings are securely encrypted at rest, but if you need secret management capabilities, they should go into Key Vault.To use a Key Vault reference for an app setting, set the reference as the value of the setting. Your app can reference the secret through its key as normal. No code changes are required.Box 2: Secrets: GetIn order to read secrets from Key Vault, you need to have a vault created and give your app permission to access it.-1. Create a key vault by following the Key Vault quickstart.-2. Create a managed identity for your application.-3. Key Vault references will use the app's system assigned identity by default, but you can specify a user-assigned identity.4. Create an access policy in Key Vault for the application identity you created earlier. Enable the "Get" secret permission on this policy.
https://docs.microsoft.com/en-us/azure/app-service/app-service-key-vault-references https://docs.microsoft.com/en-us/azure/app-service/app-service-key-vault-references
HOTSPOT (Drag and Drop is not supported)You deploy several Azure SQL Database instances.You plan to configure the Diagnostics settings on the databases as shown in the following exhibit.Use the drop-down menus to select the answer choice that completes each statement based on the information presented in the graphic.Note: Each correct selection is worth one point.Hot Area:
Box 1: 90 daysAs per exhibit.Box 2: 730 daysHow long is the data kept?Raw data points (that is, items that you can query in Analytics and inspect in Search) are kept for up to 730 days.
https://docs.microsoft.com/en-us/azure/azure-monitor/app/data-retention-privacy
You have the resources shown in the following table:CDB1 hosts a container that stores continuously updated operational data.You are designing a solution that will use AS1 to analyze the operational data daily.You need to recommend a solution to analyze the data without affecting the performance of the operational data store.What should you include in the recommendation?
Answer(s): C
Azure Synapse Link for Azure Cosmos DB creates a tight integration between Azure Cosmos DB and Azure Synapse Analytics. It enables customers to run near real-time analytics over their operational data with full performance isolation from their transactional workloads and without an ETL pipeline.
https://docs.microsoft.com/en-us/azure/cosmos-db/synapse-link-frequently-asked-questions
You have an Azure App Service app named App1.You need to recommend a solution to monitor the response times of App1 for end users. The solution must minimize administrative effort.What should you include in the recommendation?
While Application Insights targets application monitoring and performance optimization, Log Analytics focuses on log management and infrastructure monitoring.Application Insights standard metricsStandard metrics are preaggregated during collection, which gives theExample:Page load network connect time (browserTimings/networkDuration)* Receiving response time (browserTimings/receiveDuration)
https://learn.microsoft.com/en-us/azure/azure-monitor/app/standard-metrics
Note: This question is part of a series of questions that present the same scenario. Each question in the series contains a unique solution that might meet the stated goals. Some question sets might have more than one correct solution, while others might not have a correct solution.After you answer a question in this section, you will NOT be able to return to it. As a result, these questions will not appear in the review screen.Your company deploys several virtual machines on-premises and to Azure. ExpressRoute is deployed and configured for on-premises to Azure connectivity.Several virtual machines exhibit network connectivity issues.You need to analyze the network traffic to identify whether packets are being allowed or denied from the Azure virtual machines to the on-premises virtual machines.Solution: Use Azure Network Watcher to run IP flow verify to analyze the network traffic.Does this meet the goal?
Azure Network Watcher IP Flow Verify allows you to detect traffic filtering issues at a VM level.IP flow verify checks if a packet is allowed or denied to or from a virtual machine. The information consists of direction, protocol, local IP, remote IP, local port, and remote port. If the packet is denied by a security group, the name of the rule that denied the packet is returned. While any source or destination IP can be chosen, IP flow verify helps administrators quickly diagnose connectivity issues from or to the internet and from or to the on-premises environment.
https://docs.microsoft.com/en-us/azure/network-watcher/network-watcher-ip-flow-verify-overview
