Free FCP_FAZ_AD-7.4 Exam Braindumps (page: 6)

Page 5 of 44
PDF with 178 Questions

An administrator has configured the following settings:



What is the purpose of executing these commands?

  1. To record the hash value and authentication code of log files.
  2. To encrypt log transfer between FortiAnalyzer and other devices.
  3. To create the secure channel used by the OFTP process.
  4. To verify the integrity of the log files received.

Answer(s): A

Explanation:

The command set log-checksum md5-auth configures FortiAnalyzer to generate an MD5 hash for each log file, along with an authentication code. This ensures that the integrity of the logs can be verified, confirming that the logs have not been tampered with.



Which statement correctly describes RAID 10 (1+0) on FortiAnalyzer?

  1. A configuration with four disks, each with 2 TB of capacity, provides a total space of 4 TB.
    B 11 combines mirroring striping and distributed parity to provide performance and fault tolerance
  2. A configuration with four disks, each with 2 TB of capacity, provides a total space of 2 T
  3. It uses striping to provide performance and fault tolerance.

Answer(s): A

Explanation:

RAID 10 combines mirroring (RAID 1) and striping (RAID 0). In a RAID 10 setup with four disks, data is mirrored across two pairs of disks, and those pairs are striped for performance. This results in improved performance and fault tolerance, but the total usable storage is 50% of the total raw storage, meaning four 2 TB disks provide 4 TB of usable space.



Refer to the exhibit, which shows the HA configuration settings of a FortiAnalyzer device.



The administrator wants to join this FortiAnalyzer to an existing HA cluster.
What can you conclude from the configuration displayed?

  1. After joining the cluster, this FortiAnalyzer will forward received logs to its peers.
  2. This FortiAnalyzer will trigger a failover after losing communication with its peers for 10 seconds.
  3. This FortiAnalyzer is configured to route HA traffic through a gateway.
  4. This FortiAnalyzer will join the existing HA cluster as the secondary.

Answer(s): B

Explanation:

The "Preferred Role" is set to Secondary, which means this FortiAnalyzer is configured to join the cluster as the secondary unit in an Active-Passive HA configuration. Other settings, such as the peer IP and serial number, confirm its setup to communicate with the primary unit.



Which two parameters impact the amount of reserved disk space required by FortiAnalyzer? (Choose two.)

  1. Total quota
  2. License type
  3. RAID level
  4. Disk size

Answer(s): C

Explanation:

RAID level affects how much disk space is reserved for redundancy and fault tolerance. For example, RAID 1 mirrors data, meaning you need more space for redundancy, while RAID 5 or RAID 6 reserves space for parity.

Disk size directly influences the total available and reserved space since the larger the disk, the more space may need to be reserved for system functions, logs, and other operations.

The total quota and license type do not directly impact the reserved disk space, though they do influence other aspects of capacity and functionality.
