Free JN0-1361 Exam Braindumps (page: 2)

Page 1 of 17
PDF with 65 Questions

Exhibit:



You work for service provider B that wants to implement a hot potato routing policy on the network so that router C uses link C-A to reach service provider A's advertised routes and router D uses link D- B to reach Service Provider A's advertised routes Currently traffic from router C is traversing the core to exit the network on router B .
Referring to the exhibit, what are two design actions that would satisfy the requirements? (Choose two.)

  1. Implement BGP-ORR
  2. Configure new IBGP neighbors between routers C and A and routers D and B
  3. Implement BGP-LS
  4. Configure the route reflector to send multiple copies of a route learned from different IBGP peers to its clients.

Answer(s): B,D



Your customer is paying for traffic prioritization and you must ensure that all traffic from their 172.27. 10.0/24 network receives top priority through your network.
Which action will satisfy this requirement?

  1. Apply a behavior aggregate classifier to the egress interface.
  2. Apply a custom rewrite rule to the ingress interface.
  3. Apply a multifield classifier to the ingress interfaces.
  4. Apply a custom scheduler map to the ingress interface.

Answer(s): C

Explanation:

We would need MF to match the address and set the forwarding class.



You are designing a service provider core network As part of the design, you must ensure that the MPLS network utilizes the traffic engineering database (TED) for path selection and resiliency. You have chosen OSPF as the IGP for your design.
In this scenario which statement is correct?

  1. You must enable traffic engineering in OSPF to populate the TED.
  2. OSPF cannot be used to populate the TED.
  3. You must disable traffic engineering in OSPF to use the TED.
  4. OSPF populates the TED by default.

Answer(s): A


Reference:

https://www.juniper.net/documentation/en_US/junos/topics/example/ospf-traffic- engineeringenabling.html



Your company is designing a new data center in a remote location that must be connected to your local data center. You have a service provider connection between the CE devices at each site. You want to implement EVPN with VXLAN services between sites, but the service provider does not offer EVPN services.
Which two statements are true in this scenario? (Choose two )

  1. The provider's edge devices must map your VXLAN VNIs to MPLS LSPs within the provider network at each site
  2. The customer's edge devices within your data center can act as VXLAN Layer 2 gateways
  3. You can still implement EVPN service across the service provider as long as there is IP reachability between the sites.
  4. The service provider must provide an MPLS-based VPN connection between sites

Answer(s): B,C
