QUESTION: 9

What information is stored in a VRF table for a BGP Layer 2 VPN? (Choose three.)

Layer 2 encapsulation
local site ID
remote interface of local CE device
logical interlace provisioned to local CE device
label-switched path

Answer(s): A,D,E

Reveal Solution Next Question

QUESTION: 10

Which two statements about wide and narrow metrics used in IS-IS are correct? (Choose two.)

Wide metrics are enabled with the wide-metrics-only parameter under protocols isis hierarchy.
Narrow metrics are enabled by default and use 8 bits in TLVs to send information.
Wide metrics are sent by default and use 24 bits in TLVs to send information.
Disabling narrow metrics results in external routes being leaked from L1 to L2 areas automatically.

Answer(s): A,B

Reveal Solution Next Question

R4 is directly connected to both RPs (R2 and R3). R4 is currently sending all joins upstream to R3 but you want to load balance the joins between both RPs.

Referring to the exhibit, which configuration change will solve this issue?

Configure the join-load-balance parameter under PIM on R4.
Configure the default route in inet.2 on R4 from R3 as the next hop to both R3 and R2.
Configure the group-range parameter to be the same on R2 and R3.
Configure the bootstrap priority on R2 to be the same as R3.

Answer(s): A

Reveal Solution Next Question
