Administrator is creating a Windows 10 VM that will be used for a virtual desktop template. After creating the VM and booting to the ISO, the administrator is unable to install Windows and receives the following error.What steps does the administrator need to take to install the OS?
Answer(s): D
Answer(s): D. Load the Virtual SCSI pass-through controller.The error message shown in the image indicates that Windows 10 setup cannot find any drives to install the OS. This is because the Nutanix AHV hypervisor uses a virtual SCSI pass-through controller to present disks to the VMs, and Windows 10 does not have a built-in driver for this device. Therefore, the administrator needs to load the Nutanix VirtIO driver for the virtual SCSI pass-through controller during the OS installation process. The Nutanix VirtIO driver package contains various drivers that are specifically used by Windows VMs hosted in the Nutanix environment to enhance their stability and performance1. The administrator can download the latest Nutanix VirtIO driver package from the VirtIO downloads page of the Nutanix support portal. The administrator can then follow these steps to load the driver and install the OS2:On the Windows 10 setup screen, click Load driver.Insert a USB drive or mount an ISO image that contains the Nutanix VirtIO driver package.Browse to the location of the driver package and select the folder that matches the OS architecture (32-bit or 64-bit).Select the vioscsi.inf file and click Next.Wait for the driver to load and then click Refresh.Select the disk where you want to install Windows 10 and click Next.
1: VirtIO Driver Versions for Windows 2: Installing Windows on AHV
Refer to Exhibit:After configuring modules for a Remote Syslog Server, the settings are as shown. The administrator notices that even though the level parameter is set to EMERGENCY, that all monitor logs are being sent.What is the likely cause of this issue?
Answer(s): C
While installing Windows 2019 on a new VM on an AHV cluster, an administrator notices there aren't any drives listed for the install.What might the problem be?
Answer(s): B
VirtIO drivers are device drivers that are specifically designed for virtualized environments. They allow the guest operating system to communicate directly with the underlying hardware, bypassing the emulation layer. This improves the performance and efficiency of the virtual machines. VirtIO drivers are supported by various hypervisors, including Nutanix AHV1.Nutanix AHV uses SCSI disks for VMs by default. However, Windows does not have native support for SCSI disks and requires VirtIO drivers to recognize them. Therefore, if an administrator is installing Windows 2019 on a new VM on an AHV cluster, they need to install the VirtIO drivers before selecting the destination disk for the installation. Otherwise, they will not see any drives listed for the install2.To install the VirtIO drivers during Windows installation, the administrator can use one of the following methods3:Use a VirtIO ISO image that contains the driver files. The administrator can download the VirtIO ISO image from the Nutanix support portal and upload it to the AHV image service. Then, they can attach the VirtIO ISO image to the VM as a CD-ROM device and load the driver from it during Windows installation.Use a Nutanix Guest Tools (NGT) ISO image that contains the driver files and other tools. The administrator can download the NGT ISO image from Prism Element or Prism Central and attach it to the VM as a CD-ROM device. Then, they can load the driver from it during Windows installation.Use a floppy disk image that contains only the driver files. The administrator can create a floppy disk image using tools such as WinImage or WinRAR and upload it to the AHV image service. Then, they can attach the floppy disk image to the VM as a floppy device and load the driver from it during Windows installation.
Nutanix AHV Networking Best Practices
Which baseline is used to identify a Zombie VM?
The correct answer is D. Fewer than 30 I/Os and less than 1000 bytes per day of network traffic for the past 21 days.A zombie VM is a type of inactive VM that is powered on but does very little activity. A zombie VM wastes host resources such as CPU, memory, disk, and network that could be used by other VMs. A zombie VM can be identified by using the VM Profile feature in Prism Central. The VM Profile feature analyzes the resource utilization of each VM and assigns it a profile based on its efficiency and impact on other VMs. The profiles are as follows1:Efficient: The VM is well-provisioned and has optimal resource utilization.Over-provisioned: The VM has more resources than it needs and has low resource utilization.Constrained: The VM has less resources than it needs and has high resource utilization.Inactive: The VM has no resource utilization and is idle or powered off.Bully: The VM has high resource utilization and causes contention for other VMs.A zombie VM is a subtype of an inactive VM that meets the following criteria2:The VM is powered on for the past 21 days.The VM does fewer than 30 read or write I/Os (total) per day for the past 21 days.The VM receives or transfers fewer than 1000 bytes per day of network traffic for the past 21 days.To identify a zombie VM, the administrator can use Prism Central to view the VM Profile dashboard and filter by profile type. The dashboard shows the number of VMs in each profile type, as well as their resource consumption and efficiency score. The administrator can also drill down into each VM to see its detailed metrics and recommendations for optimization.
VM Profile
An administrator manages a cluster and notices several failed components shown in the exhibit.What two options does the administrator have to run all NCC checks manually? (Choose two.)
Answer(s): A,B
Prism Element and NCC are two ways to run all NCC checks manually on a Nutanix cluster. Prism Element is the web console that provides management and monitoring capabilities for a single Nutanix cluster. Prism Element has a Health dashboard that shows the status of various components and services in the cluster, such as disks, nodes, CVMs, NCC, and alerts. The Health dashboard also allows the administrator to run NCC checks manually by using the Actions drop-down menu on the right side of the screen. The administrator can choose to run all NCC checks or specific checks based on the category or severity. The NCC checks will run in the background and generate a report that can be viewed or downloaded from the Summary tab. This method is easier and faster than running NCC from the command line on the CVM.NCC stands for Nutanix Cluster Check, which is a framework of scripts that performs system checks and validations on Nutanix clusters. NCC can detect issues related to hardware, software, configuration, hypervisor, networking, and more. NCC can be run from the command line interface (CLI) of any CVM in the cluster by using the ncc command. To run all NCC checks manually, the administrator can use the command ncc health_checks run_all, which will execute all available checks and display the results on the screen. This method is more comprehensive and detailed than running NCC from Prism Element.
: [Health Dashboard - Prism Element Guide] : [Nutanix Cluster Check (NCC) - Nutanix Support & Insights] : [Running NCC Checks - Nutanix Support & Insights]
