Free 200-301 Exam Braindumps (page: 44)

Page 43 of 350
PDF with 1395 Questions

What are two reasons to implement IPv4 private addressing on a network? (Choose two.)

  1. To enable internal applications to treat the private IPv4 addresses as unique
  2. To facilitate renumbering when merging networks
  3. To expand the routing table on the router
  4. To provide protection from external denial-of-service attacks
  5. To conserve global unique IPv4 addresses

Answer(s): A,E



Which concern is addressed with the use of private IPv4 addressing?

  1. Lack of routing protocol support for CIDR and VLSM
  2. Lack of security protocols at the network perimeter
  3. Lack of available TCP/UDP ports per IPv5 address
  4. Lack of available publicly routable unique IPv4 address

Answer(s): D



What is the path for traffic sent from one user workstation to another workstation on a separate switch in a three-tier architecture model?

  1. access “" core “" access
  2. access “" distribution “" distribution “" access
  3. access “" core “" distribution “" access
  4. access “" distribution “" core “" distribution “" access

Answer(s): D



What is the difference between IPv6 unicast and anycast addressing?

  1. An individual IPv6 unicast address is supported on a single interface on one node, but an IPv6 anycast address is assigned to a group of interfaces on multiple nodes.
  2. IPv6 anycast nodes must be explicitly configured to recognize the anycast address, but IPv6 unicast nodes require no special configuration.
  3. IPv6 unicast nodes must be explicitly configured to recognize the unicast address, but IPv6 anycast nodes require no special configuration.
  4. Unlike an IPv6 anycast address, an IPv6 unicast address is assigned to a group of interfaces on multiple nodes.

Answer(s): A
