QUESTION: 17

An enterprise has two WLANs configured on WLC. It is reported that when converting APs to FlexConnect mode, WLAN A works but WLAN B does not. When converting APs to local mode, WLAN B works, but WLAN A does not. Which action is needed to complete this configuration?

Create a Cisco FlexConnect group with WLAN-VLAN mapping.
Disable local switching on the WLANs.
Map the AP group to the WLAN interface.
Join the APs to a Cisco FlexConnect group.

Answer(s): A

Reveal Solution Next Question

QUESTION: 18

An engineer wants the wireless voice traffic class of service to be used to determine the queue order for packets received, and then have the differentiated services code point set to match when it is resent to another port on the switch. Which configuration is required in the network?

Platinum QoS configured on the WLAN
WMM set to required on the WLAN
msl qos trust dscp configured on the controller switch port
msl qos trust cos configured on the controller switch port

Answer(s): D

Reveal Solution Next Question

QUESTION: 19

When using a Cisco Catalyst 9800 Series Wireless Controller, which statement about AutoQoS is true?

It has a set of predefined profiles that you cannot modify further
It matches traffic and assigns each matched packet to QoS groups
It automates deployment of wired QoS and makes wireless QoS implementation easier
It allows the output policy map to put specific QoS queues into specific subgroups

Answer(s): B

Reveal Solution Next Question

QUESTION: 20

A network engineer is deploying 8865 IP phones with wireless clients connected to them. In order to apply the appropriate QoS, the IP voice traffic needs to be distinguished from client data traffic. Which switch configuration feature must be enabled?

Voice VLAN
QBSS
WME
QoS routing

Answer(s): A

Reveal Solution Next Question
