QUESTION: 13

Routers R1 and R2 are configured for BGP. Both routers are in AS 65234. Routes from Router R2 are in the BGP table on Router R1, but not in the IP routing table. What could be the cause of this problem?

Synchronization is off
BGP multi-hop is disabled on Router R1
The next-hop of these routes can not reach by router R1
The BGP peers are down

Answer(s): C

Reveal Solution Next Question

QUESTION: 14

What is the destination IP address of routing update packets sent by RIPv2?

255.255.255.255
224.0.0.1
224.0.0.5
224.0.0.9
224.0.0.10

Answer(s): D

Reveal Solution Next Question

QUESTION: 15

The LS Sequence Number field is used to detect expired and duplicate LSAs. This field is a signed 32-bit integer and therefore the minimum LS Sequence Number is 0x800000000.

FALSE
TRUE

Answer(s): A

Reveal Solution Next Question

QUESTION: 16

Which types of prefixes will a router running BGP most likely advertise to an IBGP peer, assuming it is not configured as a route reflector?

Prefixes received from EBGP peers and prefixes received from route reflectors
All prefixes in its routing table
Prefixes received from EBGP peers and prefixes locally originated via network statements or imported
Prefixes received from other IBGP peers, prefixes received from EBGP peers, and prefixes imported to BGP
Prefixes received from other IBGP peers and prefixes received from router reflectors
Prefixes received from any other BGP peer and prefixes locally originated via network statements or imported

Answer(s): C

Reveal Solution Next Question
