Your network contains an on-premises Active Directory Domain Services (AD DS) domain named contoso.com. The domain contains three servers that run Windows Server and have the Hyper-V server role installed. Each server has a Switch Embedded Teaming (SET) team.You need to verify that Remote Direct Memory Access (RDMA) and required Windows Server settings are configured properly on each server to support a failover cluster.What should you use?
Answer(s): D
https://github.com/Microsoft/Validate-DCB
HOTSPOT (Drag and Drop is not supported)You plan to deploy an Azure virtual machine that will run Windows Server.You need to ensure that a Microsoft Entra user named user1@contoso.com can connect to the virtual machine by using the Azure Serial Console.What should you do? To answer, select the appropriate options in the answer area.Note: Each correct selection is worth one point.Hot Area:
Answer(s): A
https://docs.microsoft.com/en-us/troubleshoot/azure/virtual-machines/serial-console-overview
HOTSPOT (Drag and Drop is not supported)You have a Windows Server container host named Server1 and an Azure subscription.You deploy an Azure container registry named Registry1 to the subscription.On Server1, you create a container image named image1.You need to store image1 in Registry1.Which command should you run on Server1? To answer, select the appropriate options in the answer area.Note: Each correct selection is worth one point.Hot Area:
https://docs.microsoft.com/en-us/azure/container-registry/container-registry-get-started-docker-cli?tabs=azure-cli#push-the-image-to-your-registry
HOTSPOT (Drag and Drop is not supported)You plan to deploy an Azure virtual machine that will run Windows Server. The virtual machine will host an Active Directory Domain Services (AD DS) domain controller and a drive named F: on a new virtual disk. You need to configure storage for the virtual machine. The solution must meet the following requirements: • Maximize resiliency for AD DS. • Prevent accidental data loss. How should you configure the storage? To answer, select the appropriate options in the answer area. Note: Each correct selection is worth one point. Hot Area:
Box 1: F Create a separate virtual data disk for storing the database, logs, and sysvol folder for Active Directory. Do not store these items on the same disk as the operating system.Box 2: None By default, data disks that are attached to a VM use write-through caching. However, this form of caching can conflict with the requirements of AD DS. For this reason, set the Host Cache Preference setting on the data disk to None.
https://docs.microsoft.com/en-us/azure/architecture/reference-architectures/identity/adds-extend-domain
DRAG DROP (Drag and Drop is not supported)You create an Azure virtual machine named Server1 that runs Windows Server. Server1 has the disk configurations shown in the following exhibit.You need to create a new 100-GB volume on Server1.Which three actions should you perform in sequence? To answer, move the appropriate actions from the list of actions to the answer area and arrange them in the correct order.Select and Place:
Step 1: Create and attach a new data disk Add a data disk. 1. Sign in to the Azure portal. 2. Search for and select Virtual machines. 3. Select a virtual machine from the list. 4. On the Virtual machine pane, select Disks. 5. On the Disks pane, select Create and attach a new disk. 6. In the drop-downs for the new disk, make the selections you want, and name the disk. 7. Select Save to create and attach the new data disk to the VM.Step 2: Initialize the disk Initialize a new data disk. 1. Connect to the VM. 2. Select the Windows Start menu inside the running VM and enter diskmgmt.msc in the search box. The DiskManagement console opens. 3. Disk Management recognizes that you have a new, uninitialized disk and the Initialize Disk window appears. 4. Verify the new disk is selected and then select OK to initialize it. 5. The new disk appears as unallocated. Right-click anywhere on the disk and select New simple volume. TheNew Simple Volume Wizard window opens. 6. Etc.Step 3: Create a new simple volume
https://docs.microsoft.com/en-us/azure/virtual-machines/windows/attach-managed-disk-portal
You have an Azure virtual machine named Server1 that runs a network management application. Server1 has the following network configurations:• Network interface: Nic1 • IP address: 10.1.1.1/24 • Connected to: Vnet1/Subnet1You need to connect Server1 to an additional subnet named Vnet1/Subnet2. What should you do?
Answer(s): C
First add another network interface to Server1, then connect it to Subnet2.Virtual network and subnets. A subnet is a range of IP addresses in the virtual network. You can divide a virtual network into multiple subnets for organization and security. Each NIC in a VM is connected to one subnet in one virtual network. NICs connected to subnets (same or different) within a virtual network can communicate with each other without any extra configuration.
https://docs.microsoft.com/en-us/azure/virtual-network/network-overview
SIMULATIONYou need to enable nested virtualization for a virtual machine named VM1 on SRV1.To complete this task, sign in the required computer or computers.
Configure Nested VirtualizationStep 1: While the virtual machine is in the OFF state, run the following command on the physical Hyper-V host, in this case on SRV1. This enables nested virtualization for the virtual machine.Step 2: Set-VMProcessor -VMName <VMName> -ExposeVirtualizationExtensions $true In our case: Set-VMProcessor -VMName VM1 -ExposeVirtualizationExtensions $trueStep 3: Start the virtual machine.Install Hyper-V within the virtual machine, just like you would for a physical server. Enable the Hyper-V role through SettingsStep 4: Right click on the Windows button and select ‘Apps and Features’.Step 5: Select Programs and Features on the right under related settings.Step 6: Select Turn Windows Features on or off.Step 7: Select Hyper-V and click OK.When the installation has completed you are prompted to restart your computer.
https://learn.microsoft.com/en-us/virtualization/hyper-v-on-windows/user-guide/nested-virtualization https://learn.microsoft.com/en-us/virtualization/hyper-v-on-windows/quick-start/enable-hyper-v
SIMULATIONSRV1 contains a virtual machine named VM1.You need attach c:\vhds\Disk1.vhdx to VM1. The solution must ensure that Disk1 can be expanded dynamically when VM1 runs.To complete this task, sign in the required computer or computers.
Step 1: Sign in to the Azure portal.Step 2: Search for and select Virtual machines. Select VM1 from the list..Step 3: On the Virtual machine pane, select Disks.Step 4: On the Disks pane, select Create and attach a new disk.Step 5: In the drop-downs for the new disk, select attach c:\vhds\Disk1.vhdxStep 6: Specify that the disk is managed.Step 7: Select Save to create and attach the new data disk to the VM.
https://learn.microsoft.com/en-us/azure/virtual-machines/windows/attach-managed-disk-portal
