QUESTION: 16

Choose the correct answer
Which SysML construct is used in an activity diagram to associate an actor of a use case with the actions that actor performs?

an activity partition enclosing the actions the actor performs
an action allocation of the actor to the actions that actor performs
an association Between the actor and the actions that actor performs
an object node to represent the actor and object flows tying that actor to the actions it performs

Answer(s): D

Show Answer Next Question

Choose the correct answer
Annex C of the SysML specification describes optional stereotypes that are useful for modeling requirements.
Which stereotype are all the other stereotypes based upon, and which properties does it add to a requirement?

«designConstraint», which adds a mandatory constraintProperty
«emanagedRequirement», which adds properties for owner and changeAuthority
«extendedRequirement», which adds properties for source, risk, and verifyMethod
«penformanceRequirement». which adds properties for performanceMeasure and performance MeasureKind
«synched Requirement», which adds properties for lastSynch. version, and corresponding ID in the requirements management tool

Answer(s): D

Show Answer Next Question

QUESTION: 18

Choose the correct answer
How can the containment relationship be used to relate requirements?

Packages may represent specifications, which can be contained m other specifications
Containment allows a requirement to be decomposed by containing sub-requirements. Packages can also contain requirements
Requirements can contain packages, which in turn can contain other requirements. This is how hierarchical specifications can be represented in SysML
Requirements cannot use containment. They cannot contain any other model elements.

Answer(s): B

Show Answer Next Question

QUESTION: 19

Choose the correct answer
What is the significance of the verify relationship?

The verify relationship is restricted to relating a requirement to a testCase only.
The verify relationship extends the refine relationship to specify how the requirement will be verified.
The verify relationship is an extension of the satisfies relationship, relating a block to a verification activity.
The verify relationship relates a requirement to some other model element such as a testCase.
activity, or interaction that can prove the requirement has been satisfied.
The verify relationship is used to prove. That the assertion of the satisfy relationship is true Thus, a verify relationship is meaningless without a corresponding satisfy relationship.

Answer(s): B
