Refer to the exhibit. Each router must be configured with the last usable IP address in the subnet. Which configuration fulfills this requirement?

  1. R7# interface FastEthernet1/0 ip address 10.88.31.127 255.255.255.192 R8# interface FastEthernet0/0 ip address 10.19.63.95 255.255.255.240 R9# interface FastEthernet1/1 ip address 10.23.98.159 255.255.255.224
  2. R7# interface FastEthernet1/0 ip address 10.88.31.126 255.255.255.240 R8# interface FastEthernet0/0 ip address 10.19.63.94 255.255.255.192 R9# interface FastEthernet1/1 ip address 10.23.98.158 255.255.255.248
  3. R7# interface FastEthernet1/0 ip address 10.88.31.127 255.255.255.240 R8# interface FastEthernet0/0 ip address 10.19.63.95 255.255.255.192 R9# interface FastEthernet1/1 ip address 10.23.98.159 255.255.255.248
  4. R7# interface FastEthernet1/0 ip address 10.88.31.126 255.255.255.192 R8# interface FastEthernet0/0 ip address 10.19.63.94 255.255.255.240 R9# interface FastEthernet1/1 ip address 10.23.98.158 255.255.255.224

Answer(s): D



How do TCP and UDP fit into a query-responsible model?

  1. TCP avoids using sequencing and UDP avoids using acknowledgments
  2. TCP establishes a connection prior to sending data, and UDP sends immediately
  3. TCP encourages out-of-order packet delivery, and UDP prevents re-ordering
  4. TCP uses error detection for packets, and UDP uses error recovery.

Answer(s): B



What provides centralized control of authentication and roaming in an enterprise network?

  1. a lightweight access point
  2. a wireless LAN controller
  3. a firewall
  4. a LAN switch

Answer(s): B



Which set of 2 4 GHz nonoverlapping wireless channels is standard in the United States?

  1. channels 1, 6, 11, and 14
  2. channels 2, 7, 9, and 11
  3. channels 2, 7, and 11
  4. channels 1, 6, and 11

Answer(s): D
