F5 301a Exam
BIG-IP LTM Specialist: Architect, Set up, Deploy (Page 2 )

Updated On: 1-Feb-2026
Page 2 of 31
PDF with 147 Questions

An LTM Specialist needs to gather website statistics such as latency and throughput on the existing virtual server. This virtual server load Balances the backend web servers.
Which F5 feature will provide this?

  1. the Performance panel
  2. the AVR module
  3. the Dashboard
  4. the Statistics panel

Answer(s): B



TWO LTM devices are in the same Device Group and configured for Ac live/Standby Failover. The LTM Specialist observes that the HA Active and Standby device constantly changes state. All network links use the default route domain A dedicated fiber ink is used for the HA connection with a latency of 250 ms but no packet loss.
What is causing the change in failover state to occur?

  1. The HA network is using the default routing domain.
  2. The HA network is using multicast IP.
  3. The HA network is not configured for mirroring.
  4. The HA network latency is too high.

Answer(s): B

Explanation:



An LTM Specialist needs to use a set of addresses to access an Internet website in an outbound configuration.
Which feature should the LTM Specialist configure?

  1. NAT pool
  2. NAT address
  3. SNAT pool
  4. SNAT address

Answer(s): C



An LTM specialist needs to upgrade a VCMP quest in an HA Setup with minimum interruption for all VCMP guest instances.
In which should the LTM Specialist perform this upgrade?

  1. Relicense the host. Failover all guest's active traffic-groups to the other host, copy image to gest, create guest UCS install and set boot location to new volume, reboot
  2. Failover this specific guest's active traffic-group to the other Host, Relicense the guest, copy image to guest , create guest UCS, install and set boot location to new volume, reboot
  3. Failover all guests' active traffic-group to the other Host, Relicense the host, copy image to guest, create guest UCS, install and set boot location to new volume , reboot
  4. Failover all guests' active traffic-group to the other host, copy image to guest, create guest UCS install and set boot location to new volume, reboot, Relicense the host

Answer(s): C

Explanation:

Switch guest, reactive, license first and then upgrade.



An LTM Specialist needs to apply SNAT using currently used SNAT pool to a new virtual server. What needs to be completed before applying that configuration change?

  1. Review connection for the selected SNAT pool and enlarge it if appropriate
  2. Make sure that the BIG-IP device is NOT operating under heavy load during peak times
  3. Verify that the IP address of the SNAT pool are in the same subnet as the pool members
  4. Verify that the IP address of the SNAT pool are in the same VLAN as the pool members.

Answer(s): A

Explanation:

SNAT does not need to in the same vlan or same network segment as the pool member, as long as the route is reachable , excluding C and D he connection information of the SNAT pool to avoid port exhaustion under high concurrency



Viewing page 2 of 31
Viewing questions 6 - 10 out of 147 questions
