F5 301a Exam
BIG-IP LTM Specialist: Architect, Set up, Deploy (Page 4 )

Updated On: 1-Feb-2026
Page 4 of 31
PDF with 147 Questions

An application is expected to maintain more than 100,000 concurrent TCP connections to a single pool member.
What is an appropriate SNAT configuration in this situation?

  1. A SNAT pool with 4 IP addresses
  2. SNAT automap enabled
  3. A static SNAT
  4. A SNAT pool with IP address

Answer(s): A

Explanation:

One IP can establish 65,535 connections only the number of snapit's IP exceeds 100,000. AT least two snaptips are required. Options B, C, and all have only IP, which is obviously not enough



AN LTM Specialist is using an external monitor evaluate the hard drive usage of a node. The monitor has marked the node down because it exceeded the specific threshold. The disk usage on the server has been corrected below the threshold, however, the node remains offline.
Which feature is causing this problem?

  1. The parameter Time Until UP has a value greater than 0
  2. The value of Manual Resume is set to No
  3. The value for UP interval is enable with a value greater than 0
  4. The value for Manual Resume is set to Yes

Answer(s): D



A web server is being overloaded with HTTPS traffic. To decrease the load on the server, the LTM Specialist and the Server. Administrator decide to perform SSL offloading on the LTM device. The configuration of the virtual server is as follows:



Which change must be made to the configuration to perform SSL offloading?

  1. Remove the clientssl and http profiles
  2. Remove the clients profile
  3. Remove the clientssl and serverssl profiles
  4. Remove the severssl profile

Answer(s): D



An LTM Specialist is configuring a new virtual server on an LTM device and assigning a SNAT pool that is already is use another virtual server. Both virtual servers use the same pool members to load balance traffic. A maximum of 35,000 users needs to be able to access each virtual server ta any time. The network architecture does NOT allow the backend servers to use the LTM device as a default gateway.
What is the minimum number of SNAT addresses required in the SNAT pool to meet the needs of the virtual servers?

  1. 2
  2. 3
  3. 4
  4. 1

Answer(s): A

Explanation:

Both vs share the same snat pool, and both use the same pool member. Then the concurrent number of snatpool will be added. For each VS, there is a maximum of 35,000 users, and those two VSs have a maximum of 70,000 users. The stem did not mention how many connections each user would have concurrently. Calculated with a minimum of 1 connection, then 70,000 connections would be concurrent. One IP can support 65,535 connection. Therefore, at least 2 or more snaptips are required



An LTM Specialist needs to create two virtual servers. The application has links for both HTTP and HTTPS version of application. The client must be persistence to a pool member, no matter which virtual server is accessed. What must be selected in the Source Address Affinity persistence profile?

  1. Match across Virtual Servers
  2. Match across Pool Members
  3. Match across Services
  4. Match across Polls

Answer(s): A



Viewing page 4 of 31
Viewing questions 16 - 20 out of 147 questions
