View Related Case Study

You have an Azure subscription that contains 1,000 virtual machines and a Log Analytics workspace named Workspace1.
You plan to collect custom JSON logs from the virtual machines and store the logs in a custom table in Workspace1.
You need to ensure that the logs are collected by using the Logs Ingestion API. The solution must prevent access to Workspace1 from the internet.
What should you include in the solution?

  1. an Azure Monitor Private Link Scope (AMPLS)
  2. the linked storage account of Workspace1
  3. Service Connector
  4. an Azure Peering Service connection

Answer(s): A

Explanation:

Instead of creating a private link for each resource the virtual network connects to, Azure Monitor uses a single private link connection using a private endpoint from the virtual network to an Azure Monitor Private Link Scope (AMPLS). The AMPLS is a set of Azure Monitor resources that define the boundaries of your monitoring network.

Resource-specific endpoints
Log Analytics endpoints are workspace specific, except for the query endpoint. As a result, adding a specific Log Analytics workspace to the AMPLS will send ingestion requests to this workspace over the private link. Ingestion to other workspaces will continue to use the public endpoints.


Reference:

https://learn.microsoft.com/en-us/azure/azure-monitor/logs/private-link-security



View Related Case Study

Your company, named Contoso, Ltd., implements several Azure logic apps that have HTTP triggers. The logic apps provide access to an on-premises web service.
Contoso establishes a partnership with another company named Fabrikam, Inc.
Fabrikam does not have an existing Microsoft Entra tenant and uses third-party OAuth 2.0 identity management to authenticate its users.
Developers at Fabrikam plan to use a subset of the logic apps to build applications that will integrate with the on-premises web service of Contoso.
You need to design a solution to provide the Fabrikam developers with access to the logic apps. The solution must meet the following requirements:
-Requests to the logic apps from the developers must be limited to lower rates than the requests from the users at Contoso.
-The developers must be able to rely on their existing OAuth 2.0 provider to gain access to the logic apps.
-The solution must NOT require changes to the logic apps.
-The solution must NOT use Microsoft Entra guest accounts.
What should you include in the solution?

  1. Azure Front Door
  2. Microsoft Entra Application Proxy
  3. Microsoft Entra business-to-business (B2B)
  4. Azure API Management

Answer(s): D

Explanation:

Many APIs support OAuth 2.0 to secure the API and ensure that only valid users have access, and they can only access resources to which they're entitled. To use Azure API Management's interactive developer console with such APIs, the service allows you to configure your service instance to work with your OAuth 2.0 enabled API.
Incorrect:
Microsoft Entra business-to-business (B2B) uses guest accounts.
Microsoft Entra Application Proxy is for on-premises scenarios.


Reference:

https://docs.microsoft.com/en-us/azure/api-management/api-management-howto-oauth2



View Related Case Study

You have a Microsoft Entra tenant that syncs with an on-premises Active Directory domain.
You have an internal web app named WebApp1 that is hosted on-premises. WebApp1 uses Integrated Windows authentication.
Some users work remotely and do NOT have VPN access to the on-premises network.
You need to provide the remote users with single sign-on (SSO) access to WebApp1.
Which two features should you include in the solution? Each correct answer presents part of the solution.
Note: Each correct selection is worth one point.

  1. Microsoft Entra Application Proxy
  2. Microsoft Entra Privileged Identity Management (PIM)
  3. Conditional Access policies
  4. Azure Arc
  5. Microsoft Entra enterprise applications
  6. Azure Application Gateway

Answer(s): A,E

Explanation:

A: Application Proxy is a Microsoft Entra feature that enables users to access on-premises web applications from a remote client. Application Proxy includes both the Application Proxy service which runs in the cloud, and the Application Proxy connector which runs on an on-premises server.
You can configure single sign-on to an Application Proxy application.
E: Add an on-premises app to Microsoft Entra ID
Now that you've prepared your environment and installed a connector, you're ready to add on-premises applications to Microsoft Entra ID.
1. Sign in as an administrator in the Azure portal.
2. In the left navigation panel, select Microsoft Entra ID.
3. Select Enterprise applications, and then select New application.
4. Select Add an on-premises application button which appears about halfway down the page in the On-premises applications section. Alternatively, you can select Create your own application at the top of the page and then select Configure Application Proxy for secure remote access to an on-premise application.
5. In the Add your own on-premises application section, provide the following information about your application.
6. Etc.
Incorrect:
Not C: Conditional Access policies are not required.


Reference:

https://docs.microsoft.com/en-us/azure/active-directory/app-proxy/application-proxy-add-on-premis es-application



View Related Case Study

Your company has IT, security, and finance departments.
You need to implement a new Azure deployment that will include multiple Azure subscriptions and management groups. The solution must meet the following requirements:
-Ensure that all policies are assigned at the management group level.
-Ensure that all the finance department resources have specific encryption policies applied.
-Ensure that only users in the IT department can create virtual machines in any Azure region.
-Ensure that users in the finance department can create virtual machines in only the East US Azure region.
-What is the minimum number of management groups you can create for the planned deployment?
-

  1. 1
  2. 2
  3. 3
  4. 4

Answer(s): B

Explanation:

One for the finance department, and one for the IT department.
Note: If your organization has many Azure subscriptions, you might need a way to efficiently manage access, policies, and compliance for those subscriptions. Management groups provide a governance scope above subscriptions.
When you organize subscriptions into management groups, the governance conditions that you apply cascade by inheritance to all associated subscriptions.
Management groups give you enterprise-grade management at scale, no matter what type of subscriptions you might have. However, all subscriptions within a single management group must trust the same Microsoft Entra tenant.
For example, you can apply a policy to a management group that limits the regions available for virtual machine (VM) creation. This policy would be applied to all nested management groups, subscriptions, and resources to allow VM creation only in authorized regions.


Reference:

https://learn.microsoft.com/en-us/azure/governance/management-groups/overview



View Related Case Study

Note: This section contains one or more sets of questions with the same scenario and problem. Each question presents a unique solution to the problem. You must determine whether the solution meets the stated goals. More than one solution in the set might solve the problem. It is also possible that none of the solutions in the set solve the problem.
After you answer a question in this section, you will NOT be able to return. As a result, these questions do not appear on the Review Screen.
Your company, named Contoso, Ltd., has a Microsoft Entra tenant named contoso.com that uses Privileged Identity Management (PIM) and is linked to an Azure subscription named Sub1.
You use Azure Backup to back up all the resources in Sub1 to a Recovery Services vault named Vault1.
An external company named Fabrikam, Inc. provides security management services to Contoso. Fabrikam has a Microsoft Entra tenant named fabrikam.com and an Azure subscription.
You need to prevent a compromised administrator account in contoso.com from modifying backup policies in and deleting backups from Sub1.
Solution: You configure Multi-user authorization (MUA) in Sub1 by using a Resource Guard from fabrikam.com.
Does this meet the goal?

  1. Yes
  2. No

Answer(s): A

Explanation:

Correct:
* You configure Multi-user authorization (MUA) in Sub1 by using a Resource Guard from fabrikam.com.
Incorrect:
* In Vault1, you generate a security PIN for critical operations.
* You configure a PIM role assignment that requires approval for activation by an administrator in contoso.com.
Note: Azure Resource Guard
Azure Resource Guard is a security feature that provides an additional layer of protection for critical Azure backup and disaster recovery operations. It helps prevent unauthorized or accidental changes to your backup and recovery configurations, mitigating risks associated with malicious or unintentional modifications.
Purpose:
Azure Resource Guard is designed to enhance the security of Recovery Services vaults and their associated backup vaults. It allows you to implement multi-user authorization (MUA) on protected operations, reducing the risk of accidental or malicious data loss.
How it works:
Resource Guard acts as a gatekeeper for critical operations, requiring approvals or permissions before sensitive changes can be made. This helps ensure that only authorized individuals can modify backup settings, delete backups, or perform other critical actions.
Key benefits:
Reduces the risk of accidental data loss or corruption.
*-> Enhances security posture by preventing unauthorized changes to backup configurations.
*-> Enables multi-user authorization, requiring approvals for sensitive operations.
Provides a granular level of control over backup and recovery operations.


Reference:

https://learn.microsoft.com/en-us/azure/backup/multi-user-authorization-concept
