QUESTION: 21

Refer to the exhibit. One of the vPC VTEPs fails to route VXLAN traffic to vPC connected hosts. When the issue was being diagnosed, it was discovered that the packets that were expected to be forwarded to the MAC address on the SWITCH-VTEP-1 are instead forwarded to the MAC address on SWITCH-VTEP-2 and then dropped. Which action resolves the issue?

Configure a distributed anycast gateway on both peers
Configure iparp synchronize under the VPC domain on both peers
Configure peer-gateway under the VPC domain on both peers
Configure a different secondary IP address for one of the vPC peers

Answer(s): B

Reference:

https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus5000/sw/command/reference/vpc/n5k-vpc-cr/n5k-vpc_cmds_i.html#:~:text=a%20port%20profile.-,ip%20arp%20synchronize,no%20form%20of%20this% 20command.

Reveal Solution Next Question

QUESTION: 22

Refer to the exhibit. An engineer troubleshoots an OSPF neighborship problem between Router R2 and Router R10. Which action resolves the problem?

Change area ID on Router R10
Resolve unicast reply from Router R2
Resolve authentication type on Router R10
Change router ID on Router R10

Answer(s): B

Reveal Solution Next Question

QUESTION: 23

Refer to the exhibit A customer network uses OSPFv2 and MP-BGP protocols A network administrator installs a new Cisco Nexus Switch in the data center but experiences a BGP RIB failure Which action solves theissue?

Change the administrative distance of OSPF to 220
Configure the route as a BGP backdoor
Use a filter list for OSPF to filter both routes
Implement next-hop-self

Answer(s): D

Reveal Solution Next Question

QUESTION: 24

An engineer is implementing a new BGP peering in their new data center. The engineer set up the BGP session that peers with the remote end. As soon as the BGP peers attempt to exchange routing prefixes, one of the BGP peers drops the connection. After reviewing the configuration, the engineer reviews the logging messages. The engineer discovers that the router is missing keepalives from the remote end and terminates the session. Which action resolves the issue?

Set the bgp transport path-mtu-discovery attribute on both peers
Set the higher values for the BGP keepalive and hold-down timers on both peers
Configure the matching BGP AS numbers between the peers
Configure the matching BGP passwords between the peers

Answer(s): B

Reveal Solution Next Question
