Free 350-601 Exam Braindumps (page: 15)

Page 14 of 125
PDF with 499 Questions

Refer to the exhibit.


Which command is run from the Guest Shell to set the description on the first five interfaces of the Cisco Nexus switch?

  1. [guestshell@guestshell ~]$ for x in {1..5}; dohost “conf t ; interface eth1/$x ; description Server$x”;
  2. [guestshell@guestshell ~]$ for x in {1..5}; do dohost “conf t ; interface eth1/$x ; description Server$x”; done
  3. [guestshell@guestshell ~]$ for x in (1..5); do dohost “conf t”; “interface eth1/$x” ; “description Server$x”; done
  4. [guestshell@guestshell ~]$ for x in (1..5); dohost “conf t ; interface eth1/$x ; description Server$x”;

Answer(s): B



An engineer must configure multiple EPGs on a single access port in a large Cisco ACI fabric without using VMM integration. The relevant access policies and tenant policies have been created. A single AAEP is used to configure the access ports in the fabric. Which two additional steps must be taken to complete the configuration? (Choose two.)

  1. The EPGs must link directly to the corresponding AAEP
  2. A contract must be defined between the EPGs
  3. The EPGs must be configured as static ports
  4. The corresponding bridge domains must be configured in legacy mode
  5. The EPGs must be linked to the correct physical domain

Answer(s): C,E



Several production and development database servers exist in the same EPG and IP subnet. The IT security policy is to prevent connections between production and development. Which attribute must be used to assign the servers to different microsegments?

  1. data center
  2. VM name
  3. IP address
  4. VMM domain

Answer(s): B


Reference:

https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/3-x/virtualization/b_ACI_Virtualization_Guide_3_1_1/b_ACI_Virtualization_Guide_3_1_1_chapter_0100.html#concept_D527CF389D4440E69A288093516B3643



An environment consists of a Cisco MDS 9000 Series Switch that uses port channels. An engineer must ensure that frames between the source and the destination follow the same links for a specific flow.
Subsequent flows are allowed to use a different link. Which load balancing method should be used to accomplish this goal?

  1. src-id/dst-id
  2. src-dst-oui
  3. src-dst-port
  4. src-id/dst-id/oxid

Answer(s): D


Reference:

https://www.cisco.com/c/en/us/td/docs/switches/datacenter/mds9000/sw/6_2/configuration/guides/interfaces/nx-os/cli_interfaces/pc.html
