Free 350-601 Exam Braindumps (page: 18)

Page 17 of 125
PDF with 499 Questions

What is a characteristic of the install all command on the Cisco Nexus Series Switch?

  1. automatically checks the image integrity
  2. continues the upgrade process if any step in the sequence fails
  3. upgrades only certain modules
  4. impacts data plane traffic

Answer(s): A



DRAG DROP (Drag and Drop is not supported)
An engineer must configure the HSRP protocol to implement redundancy using two Cisco Nexus Series Switches, in addition, me HSRP must meet these requirements:

•switch1 must retain the primary role if switch2 goes offline.
•switch1 must retain the primary role until normal conditions are restored.
•switch1 and switch2 must ensure that the routing tables are converged before taking the active role.
•switch2 must retain the primary role if the default gateway is not reachable.

Drag and drop the configuration commands from the right to the left to meet the requirements. The commands are used more than once. Not all commands are used.

  1. See Explanation section for answer.

Answer(s): A

Explanation:



Refer to the exhibit.


During a vPC peer switch reload, there is packet loss between the server and the router. Which action must be taken to prevent this behavior during future reloads?

  1. Set the routed uplink ports of the Cisco Nexus peers as orphans.
  2. Increase the vPC delay restore timer.
  3. Disable vPC ARP synchronize on the vPC peers.
  4. Decrease the OSPF hello and dead interval timers.

Answer(s): B



A Cisco ACI engineer must configure an access port on a Cisco ACI leaf switch. The access policy should be configured so that it supports L3Out connectivity concurrently with several EPGs that are mapped to this interface with the static port method. How should the access policy be configured?

  1. by linking the interface policy group to multiple Attachable Access Entity Profiles
  2. with two interface policy groups that are linked to the same interface profile port selector
  3. by mapping a single physical domain, mapped to the L3out and EPG interfaces
  4. with a single Attachable Access Entity Profile that is linked to the corresponding routed domain and physical domain

Answer(s): D
